Hankook HB-110 Horizontal Table type CNC Turning Machine

SKU: hankookhb110
Manufacturer part number: HB110
Vendor:

✔ Operates is research, development and manufacture of advanced products for defense industry.
✔ Located in Turkey

Warehouse: Turkey
Brand/Model: HANKOOK HB-1102 Purpose: CNC Horizontal Machining Center Quantity: 1 Supply Year: 2003 Status: Working: The device is actively working and has no fault. Dismantling Note: The device is currently mounted. It is suitable to be transported after being dismantled.

Inspection:

The majority of the equipment listed for sale is used and may contain defects that are not detectable immediately. Prior to making a purchase, buyers may inspect the property and the inspections should be planned ahead of time. Please contact Stokarti to set an inspection appointment.

Special Guidelines:

All property is offered for sale 'AS IS, WHERE IS'. Regarding the suitability or merchantability of the goods offered for sale, Stokarti makes no warranty, guaranty or representation of any kind, either express or implied. Please be aware that all sales are final once the products are removed.

Statement of Warranty:

The seller guarantees to the buyer that the provided property will match its description. Any claim for misidentification must be submitted before the property is removed. If seller verifies that the asset, property does not match the description of the property, seller will keep the asset and return any payments made. The seller's obligation is limited only to the actual purchase price of the asset.

*
*
*
FeatureDetail
Axes4-axis or 4+1 axis
Stroke (X-Y-Z)1800 mm x 1500 mm x 1300 mm
W-axis (Boring spindle axial movement)650 mm
Motor Speed5-2500 rpm (3 steps)
Main Motor Capacity18.5/22 kW (continue/30 minutes)
Boring Spindle DiameterØ110
Milling Spindle DiameterØ195
Spindle TaperISO #50, 7/24 taper
Table Size1400 x 1600 mm
Load on Rotary Table7 tons (7000 kgf)
Rapid Traverse (X, Y, Z-axis)10000 mm/min
Machine Weight30 tons (30000 kgf)
Machine Dimensions (L x W x H)7760 x 8109 x 4100 mm (standard)
Electric Power380 Vac, 50 Hz, 60 kVA
Air Pressure250 NL/min², 5 kg/cm² (or 250 NL/min (5kg/cm²))
