📏 Boom & Reach
- Horizontal Reach: 105 ft (32 m)
- Boom Design: Four-section telescopic boom
- Base section: steel
- Three telescopic sections: aluminum (lightweight and strong)
- Unfolding Height: 16 ft (4.8 m)
- 360° Rotation: Allows flexible placement from multiple angles
🔄 Conveyor System
- Main Conveyor Belt Width: 18 in (457 mm)
- Main Belt Type: 2-ply nylon core, vulcanized spliced (no staples or mechanical splices)
- Belt Speed Control: Infinitely variable from 0 to 10
- Max Rated Output: Up to 360 yd³/hr (275 m³/hr)
🚚 Feed Conveyor
- Length: 40 ft (12.19 m)
- Design: 3-section “floating” hydraulic feed conveyor
- Rotation: 360° for versatile loading
- Material Compatibility: Sand to 4 in (100 mm) rock
- Feeding Options: Mixer truck, dump truck, skid-steer, or front-end loader
🕹️ Controls & Operation
- Control System: Modular Boom Control (MBC) for easy maintenance
- Remote Control:
- Standard proportional radio remote
- 90 ft (27 m) cable remote for restricted sites
- Manual Backup: Operator’s control station for emergency use
🧱 Material Handling
- Concrete Slump Range: 0" to 12" (0 to 305 mm)
- No Priming Required: Handles harsh mixes without admixtures
This model is ideal for jobs requiring low setup height and high placement flexibility, such as bridge decks, foundations, and tight urban sites.
